Ultrasonic wiring harness terminal welding ST series

  • Product Introduction: Ultrasonic wiring harness terminal welding is a complete ultrasonic welding equipment that integrates a digital ultrasonic generator and controller, and an ultrasonic welding press. It has multiple welding modes and multiple monitoring modes, which can meet customers stringent welding quality requirements.

Whatsapp：+86-13776317970
Correo electrónico：rui.zhang@hyusonic.com
Ultrasonic wiring harness terminal welding ST series

Ventajas del producto

Full series with European and American devices

  • Real-time monitoring of pressure Multi-stage pressure control

    Real-time monitoring of pressure

  • Constant amplitude output Multi-stage amplitude control

    Constant amplitude output
    Multi-stage amplitude control

  • Ultrasonic amplitude

    Ultrasonic amplitude fine adjustment
    10% - 100%

  • Automatically identify defective products Parameter overload protection system

    Automatic identification of defective products
    Parameter overload protection system

Características Características

  • High-strength rigid structure designHigh strength
    Rigid structure design
  • Color touch screen adjustable angle heightColor touch screen
    Adjustable angle
  • Electronic pressure measurement deviceMultiple
    Welding modes
  • Database data storageMultiple quality
    Control monitoring window
  • USB interface weldingWelding parameters
    Almacenamiento de datos
  • USB interface weldingSoldadura por interfaz USB
    Database reading

Technical parametersTechnical parameters

Technical data Frequency 20kHz/28kHz/30kHz/35kHz/40kHz
Input voltage 220V±10%50/60HZ unidirectional voltage
Input current 10-20AMAX. Current at full power load
Output power 800W/1200W/2000W/2500W/3000W/3600W/4000W/4500W/5000/6000W/10000W
Welding
(Range/Accuracy)		 Range 1ws-9999ws
Welding Accuracy 0.01mm
Welding Time Range 0.01s-10s Accuracy 1ms
Drive requirements

 Pressure 3000N
Stroke 20-50mm/or customized
Dimensions
 Rack (width x depth x height) 360mm×550mm×1280mm

Application IndustriesApplication Industries

  • Medical Products

    Wire terminal welding

  • Medical supplies welding

    Multi-layer copper sheet welding

  • Electrical supplies welding

    Soldadura de mazos de cables

  • Electronic product welding

    Soldadura de barras de cobre

  • Filter welding

    Electric vehicle battery line

  • Mask product welding

    Sheet metal welding

  • Charger welding

    Wire harness

  • Textile non-woven fabrics

    Wire terminal welding

Technology application solutions APPLICATION SOLUTIONS

Sample Case




Our partners

Ultrasonic wiring harness terminal welding ST series20
Ultrasonic wiring harness terminal welding ST series21
Ultrasonic wiring harness terminal welding ST series22



Ultrasonic wiring harness terminal welding ST series23
Ultrasonic wiring harness terminal welding ST series24
Ultrasonic wiring harness terminal welding ST series25
